Ducati Hypermotard 950 Rear Turn Signals Instructions

Ducati Hypermotard 950 Rear Turn Signals Instructions

1) Remove (2) bolts with a 4mm allen key to take off panel underneath. (Picture 1)

2) Unplug main connector. (Picture 2)

3) Remove (3) bolts with a 6mm allen key and slide off stock tail section. (Picture 3)

4) Remove (4) torx bolts to expose connectors inside stock tail section and unplug the 3 of them. (Picture 4)

5) Take new turn signal bracket and mount to existing holes with stock 6mm hardware. (Picture 5)

6) Mount panel you removed in step 1 back on bike using stock 4mm hardware. (Picture 6)
