Harley Davidson V-ROD Fender Eliminator Instructions

1) Remove (2) bolts underneath seat to take off plastic shield (picture 1)

2) Disconnect (2) plugs (picture 2)

3) To remove fender, move ECU panel out of the way and remove (4) bolts (picture 3)

4) Unbolt (2) 4mm and (2) 3mm bolts to remove stock license plate bracket (picture 4)

5) Use (2) 3mm bolts and reuse to mount stock tail light (picture 5)

6) Mount NRC license plate bracket to new fender eliminator using M6x10 bolts and nylon nuts (picture 6)

7) With provided 10-32 x 1.25 bolts and 3/4” spacers, mount NRC fender eliminator (picture 7)

8) Zip tie harness up through fender and up underneath seat

9) Plug in harness

10) Mount seats
