Honda CB300R Front Turn Signals Instructions

1) Remove (2) bolts on either side of the headlight with a 5mm allen key. (Picture 1)

2) Remove (2) bolts behind dash with a 5mm allen key. (Picture 2)

3) Remove bolt on turn signal bracket with a 5mm allen key. (Picture 3)

4) Unplug OEM connectors. (Picture 4)

5) Remove nut with an 8mm socket and slide off stock turn signal. You will need to slide out bolt and steel sleeve to get the signal off the bike. (Picture 5/6)

6) Slide connector on new turn signal through hole, and mount signal using stock hardware. (Picture 7)

7) Plug in connectors and check.
