MV Agusta Brutale 800 / RR Front Signals (2017 - Present) Instructions

MV Agusta Brutale 800 / RR Front Signals (2017 - Present) Instructions

1.) Remove (4) bolts with 5mm allen key or socket to remove headlight

2.) Unplug 3 connectors; 1 main harness, 2 turn signal connectors

3.) Remove (1) bolts on either side of headlight with 5mm allen key or socket to take off turn signal brackets

4.) Using a 4mm allen key or socket, remove stock bolt mounting turn signal and disassemble

5.) Take NRC signal, and remove (2) screws holding lower plate as this needs to mount first

6.) Take white spacer and slide into rubber grommet

7.) With provided M5 bolt and nut, mount lwoer signal bracket making sure not to overtighten. Blinker will flex inside rubber grommet if you do

8.) Reinstall (2) screws to mount lens and top plate

9.) Remount turn signal brackets to highlight

10.) Plug connectors back into harness on backside of highlight

11.) Remount headlight using stock hardware
