Suzuki GSX-250R Fender Eliminator (2017-Present) Instructions

Suzuki GSX-250R Fender Eliminator (2017-Present) Installation Instructions

1) Remove (2) seat bolts with a 5mm allen key (picture 1)

2) Remove (2) Philips head screws and (2) push pins to take off seat tray (picture 2)

3) Remove second seat tray by taking out (3) push pins (picture 3)

4) Unplug (6) barrel connectors but leave the white 3 pin connector

5) Remove (4) 10mm bolts under stock tail section and slide fender off (picture 4)

6) Take NRC kit, and put M6x25mm bolts and (2) spacers through lens bracket and mount onto the bike (picture 5/6)

7) Feed wires underneath seat and plug into harness. Check signals and plate light prior to putting the seat back together.

8) Reinstall both seat trays and seat
