Yamaha MT-10 Fender Eliminator (2018-2021) Instructions

Yamaha MT-10 Fender Eliminator (2018-2021) Installation Instructions

1) Remove seat from bike

2) Remove (3) phillips head screws. (Picture 1)

3) Remove (4) M6 allen bolts, 2 from each side. (Picture 2)

4) Remove (4) bolts with an 8mm socket. (Picture 3)

5) Unplug turn signals connectors. (Picture 4)

6) Unplug tail light connector, remove (4) 10mm nuts, and slide stock tail section off bike. (Picture 5)

7) Take new fender eliminator and mount onto the bike using the 4 holes the stock tail section used. You will have (4) M6x25 bolts, and (4) flange nuts. (Picture 6)

8) Mount your license plate using the M6x12 bolts and thread into the nut inserts in the turn signal bracket. (Picture 7)

9) Press on black rubber cap to protect key lock. (Picture 8)

10) Plug in connectors and test everything to ensure turn signals and plate light is working properly

11) Reinstall previously removed brackets and plastics.
